89 Items Match Your Search

Free Shipping Coupon Now Available on Most Orders Over $25!
Coupon applicable for use within the USA including Alaska and Hawaii. Please use coupon code FREESHIP when checking out. EXCLUSIONS: 500 foot and 1000 foot rolls of wire; flammable and/or hazardous chemicals; and any order in excess of 15 pounds combined weight. Coupon also DOES NOT apply to: International orders, oversize, truck or expedited shipping charges. Void where prohibited by law.

Part #
Description
Price
Add To Cart
**************************************TRIACS**************************************
*******************CROSS REFERENCED TRIAC DEVICES******************
*******PLEASE E-MAIL OR CALL US FOR CROSS REFERENCES********
*************ARRAIGNED BY (MAXIMUM CURRENT HANDLING)************
*
56550.8 AMPS 200 VOLTS TRIAC: Igt: 5ma (max) Vgt: 2.2v (max) Vf (on): 1.9v (max) firing quads: ALL.....TO-92 PACKAGE    $1.83
56560.8 AMPS 400 VOLTS TRIAC: Igt: 5ma (max) Vgt: 2.2v (max) Vf (on): 1.9v (max) firing quads: ALL.....TO-92 PACKAGE    $2.07
56570.8 AMPS 600 VOLTS TRIAC: Igt: 5ma (max) Vgt: 2.2v (max) Vf (on): 1.9v (max) firing quads: ALL.....TO-92 PACKAGE    $4.35
*
56402.5 AMPS 100 VOLTS TRIAC: Igt: 25ma (max) Vgt: 2.2v (max) Vf (on): 1.8v (max) firing quads: ALL.....TO-5 PACKAGE    $6.28
56502.5 AMPS 100 VOLTS TRIAC: Igt: 3ma (max) Vgt: 2.2v (max) Vf (on): 2.2v (max) firing quads: ALL.....TO-5 PACKAGE    $6.33
56412.5 AMPS 200 VOLTS TRIAC: Igt: 25ma (max) Vgt: 2.2v (max) Vf (on): 1.8v (max) firing quads: ALL.....TO-5 PACKAGE    $5.80
56512.5 AMPS 200 VOLTS TRIAC: Igt: 3ma (max) Vgt: 2.2v (max) Vf (on): 2.2v (max) firing quads: ALL.....TO-5 PACKAGE    $7.05
56422.5 AMPS 400 VOLTS TRIAC: Igt: 25ma (max) Vgt: 2.2v (max) Vf (on): 1.8v (max) firing quads: ALL.....TO-5 PACKAGE    $7.30
56522.5 AMPS 400 VOLTS TRIAC: Igt: 3ma (max) Vgt: 2.2v (max) Vf (on): 2.2v (max) firing quads: ALL.....TO-5 PACKAGE    $9.55
56432.5 AMPS 600 VOLTS TRIAC: Igt: 25ma (max) Vgt: 2.2v (max) Vf (on): 1.8v (max) firing quads: ALL.....TO-5 PACKAGE    $9.88
56532.5 AMPS 600 VOLTS TRIAC: Igt: 3ma (max) Vgt: 2.2v (max) Vf (on): 2.2v (max) firing quads: ALL.....TO-5 PACKAGE    $13.73
*
56014 AMPS 50 VOLTS TRIAC: Igt: 30ma (max) Vgt: 2.5v (max) Vf (on): 2.0v (max) firing quads: I, III-TO-126 PACKAGE    $2.43
56024 AMPS 100 VOLTS TRIAC: Igt: 30ma (max) Vgt: 2.5v (max) Vf (on): 2.0v (max) firing quads: I, III-TO-126 PACKAGE    $2.67
56034 AMPS 200 VOLTS TRIAC: Igt: 30ma (max) Vgt: 2.5v (max) Vf (on): 2.0v (max) firing quads: I, III-TO-126 PACKAGE    $2.82
56054 AMPS 400 VOLTS TRIAC: Igt: 30ma (max) Vgt: 2.5v (max) Vf (on): 2.0v (max) firing quads: I, III-TO-126 PACKAGE    $3.30
560494 AMPS 500 VOLTS TRIAC: Igt: 10ma (max) Vgt: 1.5v (max) Vf (on): 1.7 (max) firing quads: ALL.....TO-220 PACKAGE    $2.31
560394 AMPS 500 VOLTS TRIAC: Igt: 25ma (max) Vgt: 1.5v (max) Vf (on): 1.7 (max) firing quads: ALL.....SOT-82 PACKAGE    $3.28
560414 AMPS 600 VOLTS TRIAC: Igt: 25ma (max) Vgt: 1.5v (max) Vf (on): 1.7 (max) firing quads: ALL.....TO-220 PACKAGE    $3.28
56074 AMPS 600 VOLTS TRIAC: Igt: 30ma (max) Vgt: 2.5v (max) Vf (on): 2.0v (max) firing quads: I, III-TO-126 PACKAGE    $5.10
*
56388 AMPS 400 VOLTS TRIAC: Igt: 10ma (max) Vgt: 2.2v (max) Vf (on): 1.6v (max) firing quads: ALL.....TO-220 ISOLATED PACKAGE    $4.62
56088 AMPS 400 VOLTS TRIAC: Igt: 10ma (max) Vgt: 2.5v (max) Vf (on): 1.5v (max) firing quads: ALL.....TO-220 PACKAGE    $3.87
56098 AMPS 600 VOLTS TRIAC: Igt: 10ma (max) Vgt: 2.5v (max) Vf (on): 1.5v (max) firing quads: ALL.....TO-220 PACKAGE    $4.22
56108 AMPS 800 VOLTS TRIAC: Igt: 10ma (max) Vgt: 2.5v (max) Vf (on): 1.5v (max) firing quads: ALL.....TO-220 PACKAGE    $6.50
56208 AMPS 800 VOLTS TRIAC: Igt: 75ma (max) Vgt: 2.0v (max) Vf (on): 2.0v (max) firing quads: ALL.....TO-220 PACKAGE    $7.15
*
562110 AMPS 25 VOLTS TRIAC: Igt: 50ma (max) Vgt: 2.0v (max) Vf (on): 1.8v (max) firing quads: I, II-TO-127 PACKAGE    $4.20
563110 AMPS 50 VOLTS TRIAC: Igt: 50ma (max) Vgt: 2.5v (max) Vf (on): 1.6v (max) firing quads: I, II, III-TO-220 PACKAGE    $3.42
561210 AMPS 50 VOLTS TRIAC: Igt: 75ma (max) Vgt: 2.5v (max) Vf (on): 1.8v (max) firing quads: ALL.....TO-127 PACKAGE    $25.30
566110 AMPS 50 VOLTS TRIAC: Igt: 40ma (max) Vgt: 2.0v (max) Vf (on): 1.8v (max) firing quads: ALL.....TO-64 PACKAGE    $6.50
563210 AMPS 100 VOLTS TRIAC: Igt: 50ma (max) Vgt: 2.5v (max) Vf (on): 1.6v (max) firing quads: I, II, III-TO-220 PACKAGE    $3.75
562310 AMPS 100 VOLTS TRIAC: Igt: 50ma (max) Vgt: 2.0v (max) Vf (on): 1.8v (max) firing quads: I, II-TO-127 PACKAGE    $5.58
561310 AMPS 100 VOLTS TRIAC: Igt: 75ma (max) Vgt: 2.5v (max) Vf (on): 1.8v (max) firing quads: ALL.....TO-220 PACKAGE    $29.90
